Paver Block Machine QT10-15 Interlocking Concrete Paving Brick / block Making Machine

FOB Reference Price:Get Latest Price
US $20,000-100,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
100 Set/Sets per Month
Port:
QINGDAO
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
hollow/porous/standard/paver block
Brick Raw Material:
Concrete
Processing:
Brick Molding Machine
Method:
Hydraulic Pressure
Automatic:
Yes
Capacity:
1800-2400/hour
Place of Origin:
Shandong, China (Mainland)
Brand Name:
HF
Model Number:
QT10-15 brick machine
Voltage:
110V-440V
Power:
63.5KW
Dimension(L*W*H):
9350-2520-2950mm
Certification:
ISO9001,CE
Warranty:
1 NYEAR
After-sales Service Provided:
Engineers available to service machinery overseas
Molding cycle:
15-25s
Pallet size:
1150x900mm
Rated pressure:
21Mpa
Vibration frequency:
4600 r/m
Exciting force:
100KN
Block size:
400*200*200mm
Raw material:
concrete
Model:
interlocking Brick Making Machine
Packaging & Delivery
Packaging Details
wooden or nude
Delivery Time
45days
Banner



Product

Brief Introduction:



QT10-15 Automatic block making machine is one of our sell best block making machine, it is full automatic work with PLC, suitable for making all types of hollow blocks, solid block, pavers, curbstones and so on. it use our latest hydraulic pressure, so can ensure the block quality very good. Now in order to suit the overseas markets and ensure the machine work more efficiently, we have used many parts of some well-known brands imported from overseas countries.



Main Technical Specifications
Overall Dimension9350x2320x2950mm
Rated pressure21Mpa
Main vibration formPlatform vibration
Cycle Time15-25 seconds
Vibrating Frequency2800-4500 rolls/minute
Motors Power63.5 KW
Pallet Size1150x900mm
Raw Materialscrushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes
Applied Productsconcrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc
Applied Fieldswidely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc

Block Kinds

Size mm

L*W*H

Cycle

Time

QTY

/Mold

Qty/hour

Qty/8hr

Hollow brick

400x200x200

15-20s

10pcs

1800-2400pcs

14400-19200pcs

Hollow brick

400x150x200

15-20s

14pcs

2520-3360pcs

20160-26880pcs

Hollow brick

400x100x200

15-20s

20pcs

3600-4800pcs

28800-38400pcs

Solid brick

290x114x90

14-16s

30pcs

6750-7700pcs

54000-61600pcs

Solid brick

240*115*53

14-16s

52pcs

11700-13300pcs

93600-106400pcs

Color brick

200*100*60

20-25s

24pcs

3420-4320pcs

27300-34500pcs

Color brick

200*100*60

20-25s

40pcs

7200-9600pcs

57600-76800pcs

Curbstone

900*150*300

14-17s

3pcs

635-770pcs

5080-6160pcs



Here are some advantages of this machine:

1. PLC control: we seleced original SIEMENS PLC combine with independently develop machine control program, assure stable and high-effciency workstatus.

2. Switches and motor: Switches is Omron and Schneider brand, The motor is SIEMENS or ABB brand.

3. Hydraulic system: hydraulic spare parts is Taiwan CALYCA brand, provide long-term and stable hydraulic pressure.

4. Material feeder: rotary type material feeding cart, the blocks get higher density and strength.

5. Mould: With heat treatment and line cutting technology processing to assure that the mould has longer service life.

6. Spare parts: we supply enough wearing parts follow the machine shipment and our after-sales services will be faster.
